The Miliboer PTFE hydrophilic PTFE folding filter

DATE:2016-09-27 09:55    source:未知      author:admin      click:
Product introduction.
Wenzhou MILI bor Filtration Technology Co Ltd microporous membrane filter, precision filter, microporous activated carbon filter, PGR, PGK series of microporous filter solution, precise microporous filtration system, thin superfine powder filtering and washing machine, new type dry ion exchanger, automatic filtration equipment, sanitary apparatus, the ozone generator and the one or two types of pressure vessels, food and pharmacy chemical machinery and equipment, PO, PPS anti-corrosion lining pipe fittings and microporous filter MILI bor folding Miliboer, hydrophilic PTFE sintered filter core, the filter material is a hydrophilic microporous PTFE membrane, raw materials collected from domestic and foreign high-quality suppliers.
The main characteristics of microporous membrane folding type filter: high retention rate, high chemical flux and low pressure difference and wide compatibility; the production process adopts unique welding processing technology, without any adhesive, no foreign body release. Meet the production requirements of food, beverage, beer, chemical, pharmaceutical and other industries.







Miliboer hydrophilic PTFE filter - hydrophilic microporous PTFE membrane filter is microporous membrane filter, precision filter, microporous activated carbon filter, PGR, PGK series of microporous filter solution, precise microporous filtration system, thin superfine powder filtering and washing machine dry ideal accessories, long service life and stable performance, interception high rate, chemical resistance and thermal stability, excellent strength, resistance to positive and negative pressure impact.
Product specifications and technical parameters
Up and down support material: Polypropylene
Support frame and structural components: Polypropylene
Filter accuracy: 0.1, 0.2, 0.45, 1 (UM)
Filter length: 5 ", 10", 20 ", 30", 40"
Sealing material: silicone rubber, nitrile rubber, EPDM rubber, fluorine rubber three
Airtight way: hot melt welding
Typical application areas:
* Pharmaceutical Industry: aseptic raw material, liquid sterilization and filtration
* chemical industry: organic solvents, all kinds of alcohols, chemical reagents, etc.
* food industry: liquor, beverage, wine, etc. Wine filter
technical parameter
accuracyum 0.1 0.2 0.45 1
flowL/min 8 13 18 30
Pure water flux reference value: 10 "filter initial value L/min (P=0.01 MPa, 1 centipoise viscosity, 25 C)
Effective filtration area: 0.6 m/10"
Filter diameter: 69 mm
Maximum operating temperature: 80 degrees Celsius, 0.17 MPa
Maximum tolerated temperature: 140 C, 0.27 MPa
Maximum positive pressure: 0.42 MPa (25 C)
Maximum back pressure: 0.28 MPa (25 C)
Sterilization conditions: 121 min 30
