Miliboer™ PP Hot melt filter element

DATE:2016-09-27 09:44    source:未知      author:admin      click:
   PP filter MILI bor MiliboerTM microporous membrane filter, precision filter (also known as polypropylene (PP) folding filter, meltblown filter, folding drum filter cartridge, folded filter, PP folded filter]) has over 5 national patents, ISO9001 certification. Is a kind of non-toxic and tasteless using superfine polypropylene as raw material, after heat melting, material injection, traction, shaped and made the reception. PP filter with uniform pore structure of dense and sparse outside deep filter, Miliboer PP filter is a new type of meltblown filter different traditional fabric filter material, this material wire diameter is very small, often less than 5-25 micron fiber, irregular porous structure, the average diameter less than 40 microns, the average pore rate of greater than 75% such a structure for controlling the filtering precision is very reliable. And has high filtration efficiency, good characteristics of acid and alkali. Can effectively remove the suspended solids and liquid particles, rust and other impurities.




The Miliboer filter PP filter using a non-toxic odor free PP material, safe and reliable source of raw materials, in the production process without any chemical production, can be directly used for drinking water and beverage products, and without any adhesive medium, no dissolved material application. Resistance to mildew, resistance to acid and alkali, organic or inorganic solvent (chlorosulfonic acid, concentrated nitric acid and oxidant except).
Functional characteristics
Can effectively remove various impurities in the liquid particle filter;
The multilayer type depth structure, a large quantity of pollutants, long service life;
The filtration flow rate, pressure difference;
You do not contain any chemical adhesives, more health, safety;
The acid, alkali, organic solvents and oils, have good chemical stability;
The low cost, easy to change.
The surface, deep, coarse and fine filter as a whole; has the characteristics of large flow, high corrosion and low cost. To stop the water rust, sediment, eggs and other large particles.
Range of use
* drinking water and food industry, water treatment and other related systems
*R.O. and general water treatment and other application fields
Filtration of acid and alkali liquids in chemical process;
Chemical raw materials, organic solvent filtration; water soluble paint, oil, paint filtration system;
Filtration of electro coating (ED), chemical solution, mechanical oil, cutting oil, heavy oil, and fuel oil filter;
Filtering of edible oil and vegetable oil;
* syrup, chocolate and other types of slurry filter;
Filtration of liquid and ink for imaging; filtration of PCB solution;
Aseptic water, ultra pure water pre filtration treatment;
Industrial water, electroplating liquid filtration, industrial pure water filtration front system.
technical parameter
Length 10 inch 5 inch 20 inch 30 inch 40 inch
Inside diameter 20mm 25mm 28mm 30mm 35mm 15mm
Outside diameter 35mm-150mm
Filtering accuracy um
5Um 10Um 20Um 50Um 100Um 1Um
Max flow T/H
0.7 1 1.5 2.5 3.5 0.5
PPF (polypropylene meltblown filter) - 10 (length 10 ") - 5 (filtering accuracy of 5 m)
PPF - P (with skeleton polypropylene meltblown filter) - 10 (10 "- 5 (length) filtering accuracy of 5 m)
PPF D (big polypropylene meltblown filter) - 10 (length 10 ") - 5 (filtering accuracy of 5 m)
Specifications: length of 5 "10" 20 "30" 40 "50" 60 "
External diameter (+ 1mm) 60 ~ 115 mm
Inner diameter (+ 1mm) 28, 30 mm filter accuracy: 1 m, 5 m, 10 m, 20 m, 30 m,, 50 m, 100 m.
Filter length: 10, 20, 30, 40 inches.
Parameter description:
Length of 5 inch, 10 inch, 20 inch, 30 inch, 40 inch
Outside diameter 60-65mm
Inside diameter 28-30mm
Accuracy 0.1-100um
Flow (0.1MPa) 1-2T/h
Pressure 0.4 MPa
Maximum applicable temperature 60
The filter is connected: such as a flat type, insert type: 215, 222, 226, three.
