Polypropylene filter element for infusion in addition to par

DATE:2016-09-26 10:19    source:未知      author:admin      click:













Using polypropylene filter material production, high velocity, high pollution characteristics make it become the most economical pre filter infusion, injection production process, the removal of particles. Wide range of chemical compatibility, can be used for a variety of acid, alkali and solvent filtration. And according to the characteristics of your filter material, such as particle content, size and other characteristics of personalized customization, improve filtering efficiency, reduce the cost of filtration.
Characteristic
- high capacity
High velocity
- wide chemical compatibility
Quality assurance
Filter in 100 thousand dust workshop and in line with the ISO9001 standard quality system of first-class production workshop manufacturing complete



technical parameter


Polypropylene filter element for infusion in addition to particle

Texture of material

Filter media

polypropylene

brace

polypropylene

Center rod, casing

polypropylene

End cap

polypropylene

O ring / washer

Three silicone rubber / EPDM / FKM / PTFE outsourcing

Sealing technology

Thermal fusion welding (without binder)

size

diameter

Phi 68

ength

5”, 10”, 20”, 30”, 40”

The filter area /10 square meters

≥ 0.65

Aperture, M

0.1, 0.22, 0.45, 0.65, 1.0, 3.0, 5.0, 10, 20

Positive pressure difference

4.2 bar@23 ℃;1.5 bar@85

sterilization

High pressure steam sterilization can be sterilized online or 123
